Products

Trilogy's product line of rail equipment, rail battery chargers and other related technology is built to the highest industry standards and specifications. Our brand's products have a proven track record of performance and reliability in a range of international rail projects and industrial applications you can learn more about here.

Click on Each Product Link Below to View Cut Sheet



Rail Battery Chargers

FEATURES

  • Power Factor Correction

  • Efficiency of 83% to 86%

  • Lightweight & Small Size

  • UART, USB, and Ethernet Connectivity

  • Web-Based Monitoring

  • Advanced Data Logging

  • Rotary Switch or PC App-Based Programming

  • Reverse Polarity and Output Transient Protection

  • Meets AREMA Standards


FEATURES

  • CEC Compliant. Efficiency of 87% Typ.

  • Lightweight & Small Size

  • NiCAD or Lead Acid Charging

  • USB and Ethernet Connectivity

  • Networkable with Data Logging

  • PC App-Based Programming

  • Reverse Polarity and Output Transient Protection

  • Meets AREMA Design Criteria. Class C

FEATURES

  • CEC Compliant. Efficiency of 90% Typ.

  • Lightweight & Small Size

  • NiCAD or Sealed lead Acid Charging

  • USB and Ethernet Connectivity

  • Networkable with Data Logging

  • PC App-Based Programming

  • Reverse Polarity and Output Transient Protection

  • Certified to AREMA C Standards

Rail Battery Charger

FEATURES

  • Networkable Monitoring of Battery

  • Manages up to 12 Cells

  • COM Port Connection to Charger

  • 12 Bi-Color LED’s for Cell Health

  • 3 Channel Display for Cell Voltage

  • Relay Contact for Alarm Function

  • Meets AREMA C Standards

FEATURES

  • Provides up to an 85W Load

  • Loads 12V-18V, 18V-28V or 28V-36V Batteries

  • 2 Pin Interface to Trilogy BMS

  • Meets AREMA Class C Standard



DC-DC Converters

FEATURES

  • 9V to 36V DC Input

  • Isolated Output

  • 600W Maximum Output Power

  • 90% Efficiency

  • Extended Temperature Range

  • No Cooling Fans Required

  • 4 Configurable 150W Modules

  • AAR Binding Post Connections

  • Trouble Alarm Relay

  • AREMA Class C Environmental

  • Power Modules Meet UL 60950-1

FEATURES

  • 9V to 36V DC Input

  • Isolated DC Output

  • Multiple Output Voltage Versions

  • 100W Maximum Output Power

  • 88% Efficiency

  • Extended Temperature Range

  • No Cooling Fans Required

  • AAR Binding Post Connections

  • AREMA Class C Environmental

  • Power Module Meets UL60950-1

  • Standard B2 Sized Mounting Plate

DCDC Image 2.png


LED Signs

FEATURES

  • Temperature Range of -30C to +70C

  • UL-48 Certified

  • 16 x 144 LED Matrix
    - LED / Pixel
    - LED Color – Red
    - LED Intensity - 1500 mcd
    - LED Diameter - 5mm
    - LED Viewing Angle – 45 degrees
    - 0.3” dot pitch

• Functional Requirements
      - 50 ADA compliant fonts

Controller Interface

        - Ethernet

        - RS422/RS485

        - Open Protocol

Memory

         - 4-Mbit of user FLASH

LED SIgn 1.png

FEATURES

  • Temperature Range of -30C to +70C

  • UL-48 Certified

  • 32 x 128 LED Matrix

         - 1 LED / Pixel
         - LED Color – Amber
         - LED Intensity - 1500mcd
         - LED Diameter - 5mm
         - LED Viewing Angle – 45 degrees

         - 0.3” Pixel Dot Pitch

  • Enclosure

         - Tamper Proof Fasteners

         - Designed to NEMA-4 Specification

         - Hinged front access covers
         - Lexan Lens

  • Functional Requirements

         - 50 ADA compliant fonts

  • Controller Interface

         - Ethernet

         - RS422/RS485

         - Open Protocol

  • Memory

         - 4-Mbit of user FLASH

  • Certification

         - UL 48 - Electric Signs

LED SIgn 2.png

FEATURES

  • Temperature Range of -30C to +70C

  • UL-48 Certified

  • 16 x 144 LED Matrix

        - 1 LED / Pixel
        - LED Color – Amber
        - LED Intensity - 1500mcd
        - LED Diameter - 5mm
        - LED Viewing Angle – 45 degrees

        - 0.3” dot pitch

  • Enclosure

        - Tamper Proof Fasteners

        - Designed to NEMA-4 Specification

        - Hinged front access covers
        - Lexan Lens

  • Functional Requirements

         - 50 ADA compliant fonts

  • Controller Interface

         - Ethernet

         - RS422/RS485

         - Open Protocol

  • Memory

         - 4-Mbit of user FLASH

LED SIgn 3.png

FEATURES

  • Temperature Range of -30C to +70C

  • UL-48 Certified

  • 32 x XXX LED Matrix

       - 1 RGB LED / Pixel
       - LED Color – Full Color
       - LED Intensity - 1500 mcd
       - LED Diameter - 5mm
       - LED Viewing Angle – 45 degrees

       - 0.3” dot pitch

  • Enclosure

       - Tamper Proof Fasteners

       - Designed to NEMA-4 Specification

       - Hinged front access covers
       - Lexan Lens

  • Functional Requirements

       - ADA compliant fonts

  • Controller Interface

       - Ethernet

       - RS422/RS485

       - Open Protocol

  • Memory

      - 32Gbit of user FLASH

LED SIgn 4.png


Phone Line Monitor & Data Loggers

FEATURES

  • Extended Temperature Range

  • Standard DIN Rain Mounting

  • 9V-36V Operation

  • Single Telephone Input

       - Adjustable Sensitivity

       - Differential Input Connection

  • 2 Relay Outputs

        - Form C Contacts

        - Off Hook Relay

        - Fault Relay

  • User Interface

        - Off Hook LED

        - Fault LED With Latched Fault Indication

        - Latched Fault Reset Button

        - Polarity LED

  • Computer Interface

        - RS232 Serial Interface

        - Open Protocol

FEATURES

  • 48 Digital Inputs

       - Differential Input Connection
       - 2000VAC Primary-Secondary Isolation

       - 2000VAC Isolation Between Banks of 4

  • 8 Analog Inputs

       - Differential Input Connection

       - 2000VAC Primary-Secondary Isolation

       - 2000VAC Isolation Between Banks of 4

  • 12 Relay Outputs

       - Normally Open Contacts
       - 2000VAC Primary-Secondary Isolation

       - 2000VAC Isolation Between Banks of 4

  • Computer Interface

       - RS232 Serial Port

       - 10/100 Ethernet
       - USB OTG for Downloading Log Files
       - 2000VAC Isolation Between COM Ports

       - 2000VAC Primary-Secondary Isolation

  • User Interface

       - User Input Buttons

       - Digital Information Display

  • Communication Protocols

       - Genisys
       - Data Train 8
       - Microlok II Peer

  • Data Storage Capability

       - Up to 64GB (MicroSD Card)

       - Real-Time Clock for Date/Time Stamping

  • Certified to AREMA Class C Standards

FEATURES

  • Small Form Factor/DIN Rail Mount

  • Trouble Alarm Relay Contact (NO)

  • Configurable Relay Output Contact (NO)

  • Isolated Digital Input (9-36VDC)

  • Isolated Analog Input (0-36VDC)

  • Eight Character User Interface Display

  • Computer Interfaces

       - Serial Port 1 - RS232
       - Serial Port 2 – Configurable RS232/422/485

       - 10/100 Ethernet
       - USB OTG for Downloading Log Files

  • Communication Protocols

       - Genisys, Data Train 8, Microlok II Peer

  • Data Storage Capability

       - Up to 64GB (via internal MicroSD card)

  • 2000VAC Isolation Channel to Channel

  • 2000VAC Isolation Primary to COM & I/O

  • Certified to AREMA Class C Standards

Power Supplies



FEATURES

  • Operates from 95 to 253 VAC input

  • 11V-14V or 24V-32V output

  • 100W Output Power

  • Power Factor Correction

  • 85% Efficient

  • Operational Redundancy and

Intelligent Load Sharing

  • Operates from -30C to +70C

  • No Cooling Fans Required

  • AAR Binding Posts for AC & DC Terminals

  • Meets AREAM 11.5.1 for Class C equipment

FEATURES

  • Operates from 95 to 253 VAC input

  • 11V-14V or 24V-32V output

  • 100W Output Power

  • Power Factor Correction

  • 85% Efficient

  • Operational Redundancy and

Intelligent Load Sharing

  • Operates from -30C to +70C

  • No Cooling Fans Required

  • AAR Binding Posts for AC & DC Terminals

  • Meets AREAM 11.5.1 for Class C equipment

FEATURES

  • AC inputs from 100VAC to 253VAC

  • 12V, 24V or 28V Output

  • 200W Maximum Output Power

  • Power Factor Correction

  • 82% Efficient

  • Operational Redundancy with two Units

  • Operates from -30C to +70C

  • No Cooling Fans Required

  • AAR Binding Post Connections

Sips 100W.jpg

FEATURES

  • Operates from 95 to 253 VAC

  • 11V-14V or 24V-32V output

  • 600W (12V) or 700W (28V) Output Power

  • Power Factor Correction

  • 85% Efficient

  • Operational Redundancy and

Intelligent Load Sharing

  • Operates from -30C to +70C

  • No Cooling Fans Required

  • AAR Binding Post AC and DC Terminals

  • Meets AREMA 11.5.1 for Class C equipment

FEATURES

  • AC inputs – 115/230VAC or 3PH 208VAC

  • 110V to 140V Programmable Output

  • 5500W Peak Power @ 70C from 3PH 208

  • 3000W Peak Power @ 70C from 115/230VAC

  • 87% - 90% Efficient

  • Over Current & Voltage Protection

  • Operational Redundancy with two Units

  • Operates from -30C to +70C

  • No Cooling Fans Required

  • AAR Binding Post Wire Connections

FEATURES

  • Operates from 95 to 253 VAC input

  • 24V-32V output

  • 1400W (28V) Output Power

  • Power Factor Correction

  • Up to 85% Efficient

  • Operational Redundancy and

Intelligent Load Sharing

  • Operates from -30C to +70C

  • No Cooling Fans Required

  • AAR Binding Post AC and DC Terminals

  • Meets AREMA 11.5.1 for Class C equipment



Rectifier Module

FEATURES

  • Extended Temperature Range

  • AAR Binding Post Connections
